Boron nitride ceramic tube sleeve

Aliases:Ceramic structural ring
Introduction
Explore boron nitride ceramic tube sleeves with precise dimensions and smooth surfaces for machinery. Their high melting point and thermal shock stability ensure reliable performance in high temperatures, resisting cracking and deformation.
Contact Us
Live
Commission
Processing by sample | Processing by drawing | Quote within 3 hours | Samples in 3-10 days
Product Details
Factory Strength
Performance VS
Commission
Boron nitride ceramic tube sleeve
*Some content and parameters are for reference only. Our company can adjust ceramic performance and customize processing according to customer needs.
Design Features

Boron nitride ceramic tube sleeves (also known as ceramic structural rings) are high-performance ceramic materials primarily used in industrial applications requiring high temperature, high pressure, and excellent electrical insulation properties. Their main characteristics and application areas are as follows:

High-Temperature Stability

Boron nitride ceramics can maintain their structure and performance at extremely high temperatures (up to 850°C in air and 2000°C in inert gases), making them suitable for high-temperature environments.

Excellent Electrical Insulation

Boron nitride offers outstanding electrical insulation, with a room temperature resistivity of up to 10^16 Ω·cm, ensuring safety in electrical applications.

Superior Thermal Conductivity

With high thermal conductivity (50-70 W/(m·K)), boron nitride is ideal for use in thermal management systems to optimize the thermal performance of equipment.

Low Thermal Expansion Coefficient

Boron nitride has a low thermal expansion coefficient (1-1.2 x 10^-6/K), maintaining dimensional stability in thermal cycling applications and reducing thermal stress issues.

Chemical Inertness

Boron nitride is highly resistant to most chemicals and corrosive environments, ensuring performance is not affected in harsh conditions.

Self-Lubricating Properties

Hexagonal boron nitride possesses a degree of lubricity, making it suitable for mechanical applications that require a low friction coefficient.

Application Areas

Semiconductor Manufacturing

Used for handling and positioning sensitive silicon wafers during the semiconductor manufacturing process. Boron nitride tube sleeves provide essential structural support and thermal management, especially during heat treatment and wafer fabrication.

Aerospace Applications

Suitable for high-temperature components in the aerospace industry, such as engine parts and thermal protection systems, where materials must withstand extreme temperatures and mechanical stress.

Electronic Devices

Used as insulators and thermal interface materials at high temperatures to protect sensitive electronic components from overheating.

High-Temperature Industrial Equipment

Employed as structural and insulating components in high-temperature industrial applications, such as heat treatment furnaces, kilns, and reactors.

Boron nitride ceramic tube sleeves, with their high-temperature stability, excellent electrical insulation, and effective thermal management capabilities, are indispensable materials in semiconductor, aerospace, and high-temperature industrial applications. Their design and material characteristics make them especially important in modern technology applications requiring high reliability and precise control, providing ideal solutions for precision equipment in extreme environments.
